Quint Audio M14

Beschrijving

Description

• 13.5″ bass reflex design combined with 3″ compression driver
• Coaxial design
• Maintained low frequency performance at full power
• Monitor angles 30 degrees and 60 degrees
• Tool free mountable U-bracket
• 2x NL4 on the front, 2x NL4 on the left, 2x NL4 on the right
• 2x ergonomic handles, 1x on the left, 1x on the right
• Rubber feet for stability on the bottom
• All Quint Audio loudspeakers are designed for use in combination with Quint Audio processors & amplifiers
• All Quint Audio loudspeaker presets are matched in level and phase at the crossover frequency for easy mix & match
• Factory system presets available

Application area

• Live monitoring
• FOH monitor
• fill
• live music
• mechanical music
• vocals
• speech

Specifications

Model: M14
Filter: 1/2-channel DSP control
Loudspeaker components: 13.5″/3″
Impedance: 8 Ohm
Peak SPL* / freq. range (-6dB): 134dB / 59Hz-16kHz
Max SPL* / freq. range (-6dB): 116dB / 59Hz-16kHz
Max SPL -10dB / freq. range (-6dB): N/A
Max SPL -20dB / freq. range (-6dB): N/A
Dispersion (HxV): 80° conical
Connections: 6x 4 pole speakON
Weight: 16 kg
Size (WxHxD): 425 x 300 x 445mm
: *Measurements are conform to AES75 and carried out with P9 processor and A42 amplifier. Values are scaled to 1m free field.
