Kind Audio KDX 30.2

Beschrijving

Model: KDX 30.2 | Number channels: 2 | Power Output per Channel | 16 ohms per ch.: 280 W N/A | 8 ohms per ch.: 550 W | 4 ohms per ch.: 1000 W | 2 ohms per ch.: 1500 W | Hi-Z distributed lines 70V (100Vp)2): 750 W | Hi-Z distributed lines 100V (141Vp)2): 400 W) | Power Output Bridged Per Channels Pair1) | 16 ohms: 1100 W | 8 ohms: 2000 W | 4 ohms: 3000 W | Performance With Gain: 32 dB | THD+N 20 Hz – 20kHz for 1 W @ 4 ohms: <0.1% | THD @ 1 kHz 1dB below clipping @ 4 ohms: <0.2% | Signal to Noise Ratio: >103 dBA | Frequency Response (1 W @ 8 ohms) +0/-1dB: 20Hz – 20kHz | Damping Factor @ 8 ohms load, 10 Hz to 200 Hz: >200 | Output Slew rate @ 8 ohms (input filter bypassed): 45V /uS | Input Impedance Balanced / Unbalanced: 20k / 10kOhm | Input CMRR: >50 dB | Gain and Level | Input Sensitivity @ 4 ohms (32 dB gain) +/- 3 %: 1.59 V | Input Gain Selectable (all channels, internal jumpers): 26, 32 dB | Default Gain: 32 dB
