RCF XPS 16K

Beschrijving

Features | 16000 W Total Continuous Power | 40-bit Floating-point Processing, up to 96 kHz | 32-bit Fixed-point Internal Routing | FiRPHASE, Bass Motion Control, Bass Shaper | RDNet Networked Management | Touch 4.3″ Color TFT Interface | Full On-board Processing with Delay, EQ, Comp/Limiter | On-board Speaker Presets Library | Specifications | AMPLIFIER SPECIFICATIONS | Amplifier Class: D | Output power (EIAJ 8:32 all channels driven): | 4 x 4000 W @ 2.7 ohm | 4 x 2600 W @ 4 ohm | 4 x 1400 W @ 8 ohm | Frequency Response (-3dB): 20 Hz ÷ 23000 Hz | SNR Analog inputs (unweighted): >111 dB | SNR Digital inputs (unweighted): >115 dB | Crosstalk: <70 dB | THD+N (20 Hz ÷ 20000 Hz,1000 W @ 4 ohm): <0.2 % | Gain (linear mode @ 0 dB): 32 dB | Damping factor (@ 4 ohm, 20 Hz ÷ 1500 Hz): >95 | Max burst length (@ 50 Hz, CF = 7 dB, 4 ohm, 1% THD+N): 200 ms | INPUT SECTION | Total number of inputs: 8 | Line inputs: 4 | Line connectors: XLR | Digital inputs: 4 | Digital connectors: XLR | Digital type: AES/EBU | General Purpose Inputs (GPI): 2 | Programmable GPI: Yes | Photo-coupled GPI: 2 | OUTPUT SECTION | Signal output number: 4 | Signal output connectors: XLR | Power output connectors: Speakon | General Purpose Outputs (GPO): 3 | Programmable GPO: Yes | PROCESSING | DSP: | 2 SHARC, 40-bit floating point, 96 kHz | 2 ADAU, 32-bit fixed point, 96 kHz | EQ Filters: Peaking | HI/LO-shelving | HI/LO-pass (Butterworth, Linkwitz-Riley, Bessel) | Advanced algorithms: FiRPHASE technology | BASS shaper | air compensation | mid-low correction | driver excursion control | dynamic PEQ | multi-band compressor | pilot tone detection | backup recovery strategy | impedance load measurement | Compressors: RMS limiter | dynamic compressor | power limiter | thermal compressor | Delay: 0 ÷ 4000 ms (each channel) | Tone controls: Yes | High-pass filter: 10 Hz ÷ 1000 Hz | Crossover: 2500 ÷ 3500 Hz | Automatic gain control: Yes | CONFIGURATION AND CONTROL | Configuration: Front panel touch screen, PC Software | Network: Gigabit ethernet | RCF speakers presets: Yes | Priority: Yes | Protocols for system integration: Proprietary OSC based protocol, Q-SYS | RDNet: Yes | PROTECTIONS | Cooling: Forced | Short circuit: Yes | Thermal: Yes | DC: Yes | Fuses: Yes | VHF (Very High Frequencies): Yes | OPERATING CONDITIONS | Temperature range – Continuous operation: -5°C ÷ +40°C / +23°F ÷ +104°F | Temperature range – Reduced output power: -5°C to +50°C / +23°F to +122°F | Fan noise idle < (dBA): <35 dBA | Fan noise max < (dBA): <64 dBA | POWER REQUIREMENT | Operating voltage: 90-240 V~ 50/60Hz | Nominal current AC @ 100-120 V: 30 A | Nominal current AC @ 220-240 V: 16 A | Stand by power consumption: 20 W | Idle power consumption: 90 W | Power consumption (MAX): 5800 W | Main fuse: Internal | STANDARD COMPLIANCE | Safety agency: | CE compliant, UL 62368-1, 3rd Ed. | CSA C22.2 No. 62368-1:19, 3rd Ed. | PHYSICAL SPECIFICATIONS | Handles: 2 metal handles for rack mount | Color: Black - RAL 9005 | Rack mounting: 19", 2U | SIZE | Height: 88.7 mm / 3.49 inches | Width: 482 mm / 18.98 inches | Depth: 482.4 mm / 18.99 inches | Weight: 15 kg / 33.07 lbs​
