Neumann KM140

Beschrijving

Acoustical operating principle: Press. grad. transducer | Directional pattern: Cardioid: | Frequency range 20 Hz … 20 kHz | Sensitivity at 1 kHz into 1 kohm: 15 mV/Pa | Rated impedance: 50 ohms | Rated load impedance: 1 kohms | Equivalent noise level, CCIR1): 25 dB | Equivalent noise level, A-weighted’): 16 dB-A | Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL): 69 dB | Signal-to-noise ratio, A-weighted’) (rel. 94 dB SPL): 78 dB | Maximum SPL for THD 0.5%2): 138 dB | Maximum SPL for THD 0.5% with preattenuation): 148 dB | Maximum output voltage: 10dBu | Supply voltage (P48, IEC 61938): 48 V ± 4 V | Current consumption (P48, IEC 61938): 2 mA | Matching connector: XLR3F | Weight: 80 g | Diameter: 22 mm | Length: 92 mm
